JIS HMD-1 Cold Worked Tool Steel

JIS HMD-1 Tool Steel Overview

1. JIS HMD-1 Tool Steel Introduction

JIS HMD-1 is a high-carbon, high-chromium cold work tool steel renowned for its exceptional hardness (58-63 HRC), wear resistance, and dimensional stability. With a composition of 0.75-0.95% carbon and 1.00-1.20% chromium, it forms dense carbides that enhance durability in abrasive environments. Its optimized heat treatment process minimizes distortion, making it ideal for complex tools like stamping dies and thread-rolling tools. Widely used in automotive, aerospace, and manufacturing industries, HMD-1 combines performance with cost-efficiency, offering extended tool lifespan under extreme conditions.

2. JIS HMD-1 Tool Steel Supply Range

JIS HMD-1 cold work tool steel is available in versatile forms to meet industrial demands:

3. JIS HMD-1 Tool Steel Chemical Composition & Global Equivalents

4. JIS HMD-1 Tool Steel Physical & Mechanical Properties

Physical Properties

Mechanical Properties

1.) Hardness: The hardness of 7CrSiMnMoV typically ranges from 58 to 62 HRC (Rockwell Hardness C scale), making it a very hard and wear-resistant material. 2.)Strength: 7CrSiMnMoV has a high tensile strength, typically ranging from 2000 to 2500 MPa, which makes it suitable for applications that require high strength and toughness.

3.) Toughness: This steel has good toughness and impact resistance, which helps prevent cracking and chipping during cutting or forming operations.

4.) Wear resistance: 7CrSiMnMoV has excellent wear resistance, which allows it to maintain its cutting edge sharpness and dimensional stability even under high-stress conditions. 5.) Corrosion resistance: This steel has good corrosion resistance, but it is not as corrosion-resistant as stainless steels. It is important to properly maintain and store tools made from 7CrSiMnMoV to prevent corrosion. 6.) Machinability: 7CrSiMnMoV is relatively easy to machine and grind, allowing for the production of complex and precise tooling components.

6. JIS HMD-1 Tool Steel Heat Treatment

1. Annealing: The steel is heated to a temperature of around 800-850°C and then slowly cooled in the furnace to relieve internal stresses and improve machinability. 2. Preheating: The steel is preheated to a temperature of around 500-600°C before the hardening process to ensure uniform heating and prevent cracking. 3. Hardening: The steel is heated to a temperature of around 1000-1050°C and then quenched in oil, water, or polymer to achieve the desired hardness and improve wear resistance. 4. Tempering: The hardened steel is then tempered by reheating it to a temperature of around 200-600°C, depending on the desired hardness and toughness. The tempering process helps to reduce internal stresses and improve the steel's toughness and impact resistance. 5. Stress relieving: To further reduce internal stresses and improve dimensional stability, the steel can be stress relieved by heating it to a temperature of around 500-600°C and then slowly cooling it in the furnace. It is important to carefully control the heating and cooling rates during the heat treatment process to achieve the desired mechanical properties for 7CrSiMnMoV tool steel. Additionally, proper post-heat treatment processes such as grinding, polishing, and coating may be required to achieve the final desired surface finish and performance of the tool steel.

6. JIS HMD-1 Tool Steel Applications

HMD-1 excels in high-precision and high-wear industrial scenarios:

• Cold Work Dies: Blanking dies, forming molds, and precision punches for sheet metal.

• Cutting Tools: Shear blades, thread-rolling dies, and woodworking knives.

• Automotive & Aerospace: Engine component molds, structural part dies, and high-stress fixtures.

Why Choose HMD-1?

• Longevity: 30% longer lifespan than conventional cold work steels (e.g., O1) in abrasive environments.

• Precision: Minimal distortion during heat treatment ensures tight tolerances for complex geometries.
